In agricultural, industrial and civil sectors, it is spreading the conviction that some of those materials described today as “scraps” can on the contrary be utilized as an outstanding source of alternative energy.
Manufactured with first quality materials, they assure long life, absolute reliability and considerable sawings on the operating costs.
BIOMASS:: exhausted olive husks, shells of nuts, walnuts, almonds, pineseeds, manure, peach and apricot seeds, pellets, coal, briquettes, etc. with a maximum relative humidity of 20%.
| Mabre GDS | 70 GDS |
140 GDS
|
240 GDS |
350 GDS
|
580 GDS
|
720 GDS
|
1100 GDS
|
1280 GDS
|
1750 GDS
|
|---|---|---|---|---|---|---|---|---|---|
| Thermic power Kcal/h | 60.000 | 120.400 | 206.500 | 301.000 | 500.000 | 620.000 | 946.000 | 1.100.000 | 1.505.000 |
| Kw | 70 | 140 | 240 | 350 | 581 | 720 | 1.100 | 1.280 | 1750 |
| Lenght mm. | 1.900 | 2.700 | 3.700 | 4.400 | 5.000 | 4.500 | 5.600 | 5.600 | 6.100 |
| Width mm. | 950 | 1.000 | 1.150 | 1.150 | 1.500 | 3.300 | 3.900 | 3.900 | 4.100 |
| Height mm. | 1.110 | 1.820 | 2.150 | 2.220 | 2.500 | 2.500 | 2.650 | 2.650 | 2.700 |
| Air capacity m3/h | 6.000 | 11.000 | 18.000 | 21.000 | 32.000 | 40.000 | on request | on request | on request |
| Weight kg. | 350 | 580 | 850 | 1.140 | 2.300 | 2.900 | 4.400 | 5.800 | 6.450 |
| Hopper m3 | 0,7 | 1,0 | 1,0 | 1,0 | 1,0 | 1,0 | 1,0 | 1,0 | 1,0 |
| Air Exit Ø mm. | 400 | 500 | 550 | 650 | 800 | 950 | on request | on request | on request |
| Chimney Ø mm. | 150 | 180 | 250 | 300 | 400 | 500 | 600 | 600 | 700 |
